Two Pot Magnets with Internal Threaded Studs

Pot Magnets with Internal Threaded Stud

Shopping With Us

Why use Bunting - eMagnets?

  • Order by 4:00pm for Next Day Delivery
  • Lines Open from 8:00am to 5:00pm
  • 5 Star Trustpilot Rating
  • World Class Technical Support
  • Volume Pricing Available On Line
  • Live chat
  • Millions of Magnets available from Stock
Clear

Pot Magnets with Internal Threaded Stud

£1.16£5.12

Clear
SKU: N/A Category:
Part #DiameterDepthHole DiameterHole TypeStud ThreadStud LengthPull (Kgs)CoatingMaterialPackage QuantityPriceQuantity
E1028 25 mm8 mmM4ThreadedM4154PaintedFerrite1 £1.80
Quantity Discount Pricing
Prices per number of Packs
MinMax£ / Pack £ / Magnet
19£1.80£1.8000
1024£1.60£1.6000
2549£1.51£1.5100
50£1.33£1.3300
E1029 32 mm7 mmM4ThreadedM4157.5PaintedFerrite1 £1.61
Quantity Discount Pricing
Prices per number of Packs
MinMax£ / Pack £ / Magnet
19£1.61£1.6100
1024£1.45£1.4500
25£1.37£1.3700
E712 25 mm7 mmM4ThreadedM4154ChromeFerrite1 £1.16
Quantity Discount Pricing
Prices per number of Packs
MinMax£ / Pack £ / Magnet
149£1.16£1.1600
5099£0.99£0.9900
100249£0.87£0.8700
250499£0.70£0.7000
500£0.58£0.5800
E715 50 mm10 mmM4ThreadedM418.522ChromeFerrite1 £5.12
Quantity Discount Pricing
Prices per number of Packs
MinMax£ / Pack £ / Magnet
149£5.12£5.1200
5099£4.35£4.3500
100249£3.84£3.8400
250£3.07£3.0700

Description

Buy Internal Threaded Stud online with Bunting – eMagnets™

Pot Magnets offer an increase in clamping force onto ferromagnetic materials because the magnets are inside a ferromagnetic casing (Ni or Zinc plated mild steel) which gives an improved magnetic circuit. This allows high clamping forces to be achieved with minimal size.

The Pot Magnet with Internal Threaded Stud / Boss Mounting has a boss / stud as part of the steel backing within which is a female threaded section. A M4 or M10 screw or bolt can be used to hold the Pot Magnet with Internal Threaded Stud / Boss Mounting in place. This group of Pot Magnets contains the Pot Magnets previously named Low Cost Pot Magnets with Threaded Boss Mounting.

The Pot Magnet with Internal Threaded Stud / Boss Mounting exists with Ferrite and NdFeB magnets within the Pot assembly. The NdFeB versions can be used up to +80 deg C and are suitable for frozen applications. The ferrite versions can be used up to +180 degrees C but may start to show some signs of weakening (demagnetisation) when used in sub-zero conditions e.g. -10 to -20 deg C. The design and application determines the actual optimal operating temperature range.

Some versions of the Pot Magnet with Internal Threaded Stud / Boss Mounting have a white painted casing. This makes them an ideal choice for Point of Sale magnets, Window Dressing magnets, Ceiling magnets and Door magnets, etc.

The Pot Magnet with Internal Threaded Stud / Boss Mounting range offers maximum clamping forces from 4kg up to 130kg with sizes ranging from 25mm to 125mm diameters.

The Pot Magnet with Internal Threaded Stud / Boss Mounting is dimensioned by giving the main Pot Magnet dimensions then giving the size of the threaded hole and finally the overall height of the Pot Magnet.

It is possible to produce bespoke Pot Magnets with Internal Threaded Stud / Boss Mounting – please contact us for a price. Please also get in touch if you would like a copy of our extended range brochure (both are subject to minimum order quantities).

Additional information

Weight N/A
Diameter

25 mm, 32 mm, 50 mm

Depth

10 mm, 7 mm, 8 mm

Hole Diameter

M4

Hole Type

Threaded

Stud Thread

M4

Stud Length

15, 18.5

Pull (Kgs)

, ,

Coating

,

Material

Ferrite

Package Quantity

1

Description

Buy Internal Threaded Stud online with Bunting – eMagnets™

Pot Magnets offer an increase in clamping force onto ferromagnetic materials because the magnets are inside a ferromagnetic casing (Ni or Zinc plated mild steel) which gives an improved magnetic circuit. This allows high clamping forces to be achieved with minimal size.

The Pot Magnet with Internal Threaded Stud / Boss Mounting has a boss / stud as part of the steel backing within which is a female threaded section. A M4 or M10 screw or bolt can be used to hold the Pot Magnet with Internal Threaded Stud / Boss Mounting in place. This group of Pot Magnets contains the Pot Magnets previously named Low Cost Pot Magnets with Threaded Boss Mounting.

The Pot Magnet with Internal Threaded Stud / Boss Mounting exists with Ferrite and NdFeB magnets within the Pot assembly. The NdFeB versions can be used up to +80 deg C and are suitable for frozen applications. The ferrite versions can be used up to +180 degrees C but may start to show some signs of weakening (demagnetisation) when used in sub-zero conditions e.g. -10 to -20 deg C. The design and application determines the actual optimal operating temperature range.

Some versions of the Pot Magnet with Internal Threaded Stud / Boss Mounting have a white painted casing. This makes them an ideal choice for Point of Sale magnets, Window Dressing magnets, Ceiling magnets and Door magnets, etc.

The Pot Magnet with Internal Threaded Stud / Boss Mounting range offers maximum clamping forces from 4kg up to 130kg with sizes ranging from 25mm to 125mm diameters.

The Pot Magnet with Internal Threaded Stud / Boss Mounting is dimensioned by giving the main Pot Magnet dimensions then giving the size of the threaded hole and finally the overall height of the Pot Magnet.

It is possible to produce bespoke Pot Magnets with Internal Threaded Stud / Boss Mounting – please contact us for a price. Please also get in touch if you would like a copy of our extended range brochure (both are subject to minimum order quantities).
